Standard & Custom FPGA / FMC Carrier Board Solutions

Professional Pure FPGA Carrier Board Custom Design & Small‑Batch Manufacturing

Off-the-shelf pure passive FPGA carrier boards and standard FMC carrier boards are rarely available as standard stock products from mainstream Chinese manufacturers.

Most suppliers market integrated FPGA boards under the name “base board” or “carrier board”, while such products are essentially all-in-one development boards with onboard FPGA, Zynq or DSP devices integrated.

To serve professional global project demands, we offer full custom design and small-batch manufacturing services for pure carrier requirements:

• Pure passive FPGA carrier boards (without onboard main FPGA chip)

• Pure FMC mezzanine carrier boards compliant with VITA 57.1 / VITA 57.4

• Custom extension base boards and system backplanes

• Dedicated carrier boards matched with FPGA core modules and SoM modules

We partner with qualified domestic high-speed hardware design and manufacturing teams, providing one-stop services including schematic design, PCB layout, impedance control, prototype validation and mass production.

Browse our reference configurations below for typical carrier board form factors and interface options.

Reference Product Selection Table

Note:

Each reference model indicates typical configuration only.

Carrier type, SoM compatibility, main interfaces and form factor are fully configurable per project demand.

Standard Configurable Options

Carrier Type

4x5 Universal Carrier, Zynq UltraScale+ Carrier, PCIe Extension Carrier, Base Carrier Board, High-End MPSoC Carrier, Entry-Level FPGA Carrier

Compatible SoM Family

4x5 Standard SoM, Zynq-7000 SoM Family, Zynq UltraScale+ MPSoC SoM, Zynq UltraScale+ RFSoC SoM, AMD Xilinx FPGA SoM, Universal FPGA SoM Module

Main Interfaces

Gigabit Ethernet, 10 Gigabit Ethernet, USB 2.0, USB 3.0, PCIe, CRUVI, GPIO, UART, I2C, SPI, FMC 1.0 VITA57.1, FMC+ VITA57.4

Form Factor

4x5 Standard SoM Form Factor, Embedded Standard Form Factor, PCIe Card Form Factor, Industrial Standard Form Factor, Base Carrier Standard Size, FMC Compatible Form Factor, Fully Custom Mechanical Size.

Further custom interfaces and extended specification options are available on request.
