VPX Storage & Recorder Boards

This portfolio includes 31 rugged 3U/6U VPX storage products: 13 VPX Storage Expansion Carriers and 18 VPX High‑Speed Recorders, for airborne, vehicle & shipborne embedded data recording.

Storage carriers are offered in three architectures: PCIe switch, PCIe direct link, parallel SATA array. M.2 NVMe, U.2, mSATA, SATA‑II supported, with multiple RAID modes. Air / conduction cooling, wide-temperature option -40℃~+85℃, VITA standard compliant.

High-speed recorders use Xilinx FPGA platforms, supporting RapidIO, Aurora, PCIe, LVDS, 10G/1G Ethernet, dynamic FPGA reconfiguration and real-time file system.

If standard models cannot fully satisfy your specs, custom modification based on our existing boards is available.




VPX Storage Expansion Carrier | Selection Table

Part Number

Form

Factor

Core

Chip

Storage

Interface &

Disk Count

Max

Capacity

PCIe

Spec

Bandwidth

Supported

 OS

Power

Consumption

Cooling &

Operating

Temp

EL12PRCA6A001

6U VPX

 4/5HP

VITA46/VITA65

fanless

PEX8796

PCIe switch

8×

M.2 NVMe

(PCIe ×4)

64TB

Software

RAID

P1:

PCIe3.0 ×16

(×8/×4

compatible)

Up to

8GB/s

R/W

 (Linux / Win10)

Windows7/10

Linux

N/A

Conduction

/

 Air Cooling

 -20~+60℃

/

-40~+85℃

EL12PRCA6A002

6U VPX

 4/5HP

VITA46/VITA65

fanless

PEX8796

PCIe switch

8×

M.2 NVMe

(PCIe ×4)

64TB

Software

RAID

P1:

PCIe3.0 ×16

(×8/×4

compatible)

Up to

 10GB/s

R/W

(Linux)

Windows7/10

Linux

N/A

Conduction

 /

Air Cooling

-20~+60℃

/

-40~+85℃

EL12PRCA6A003

6U VPX

 5HP

VITA46/VITA65

fanless

PEX8748

PCIe switch

8×

M.2 NVMe

(PCIe ×4)

32TB(wide)

/

64TB(ambient)

Software

RAID

P1:

PCIe3.0

×16/×8/×4

6.2GB/s

Write

 /

6.7GB/s

Read

(SSD limited)

Windows7/10

 Linux

VxWorks

Domestic OS

N/A

Conduction

 /

Air Cooling

-20~+60℃

/

-40~+85℃

EL12PRCA6A004

6U VPX

 5HP

VITA46/VITA65

fanless

PEX8796

PCIe switch

8×

M.2 NVMe

(PCIe ×4)

32TB

Software

RAID

P1:

PCIe3.0

×16/×8/×4

6.2GB/s

Write

 /

6.7GB/s

Read

(OS limited)

Windows7/10

Linux

VxWorks

Domestic OS

N/A

Conduction

 /

Air Cooling

-20~+60℃

/

-40~+85℃

EL12PRCA6A0056U VPX

PEX8748

 PCIe switch

3×

U.2 NVMe

SSD

15.36TB

per drive,

Hardware

RAID

P1:

PCIe3.0 ×16

uplink,

3×PCIe3.0×4

downstream

(8GT/s max)

Sustained

 read /

write

5GB/s

N/A<75W

Conduction

 /

Air Cooling

0℃~50℃

/

-40℃~60℃

EL12PRCA6A006

3U VPX

 4/5HP

fanless

PEX8725

PCIe switch

3×

M.2 NVMe

(PCIe ×4)

12TB

Software

RAID

P1:

PCIe3.0 ×8

(to front panel

 miniSAS);

P2:

PCIe3.0 ×8

6.2GB/s

Write

 /

6.7GB/s

Read

(OS limited)

Windows7/10

 Linux

VxWorks

Domestic OS

N/A

Conduction

 /

Air Cooling

 -20~+60℃

/

-40~+85℃

EL12PRCA6A007

3U VPX

 4/5HP

VITA46/VITA65

fanless

PEX8725

PCIe switch

3×

M.2 NVMe

(PCIe ×4)

12TB

Software

RAID

P1:

PCIe3.0 ×8

6.2GB/s

Write

 /

6.7GB/s

Read

 (OS limited)

Windows7/10

 Linux

VxWorks

Domestic OS

N/A

Conduction

 /

Air Cooling

 -20~+60℃

/

-40~+85℃

EL12PRCA6A0083U VPX

No PCIe switch

2×independent

PCIe3.0 ×4

direct links

2×

U.2 NVMe

Single channel

selectable

(1 or 2 SSD

 configurable)

SSD

Capacity

Customer

Defined

PCIe3.0,

U.2 routed to

VPX P1/P2

SSD

 dependent,

up to

PCIe3.0 ×4

per channel

N/AVPX backplane powered; power subject to SSD

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A0096U VPX

PEX8732

 PCIe switch

+ CPLD

3×

M.2 NVMe

SSD

Not specified

Software

RAID

PCIe3.0 ×16 Upstream (config ×8/×4); 3×PCIe3.0 ×4 Downstream, optional extra ×4, PCIe2.0 compatible, max 8GT/s

N/AN/AN/A

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A0106U VPX

No PCIe switch

4×independent PCIe3.0 ×4

Direct links

4×

M.2 NVMe

SSD

15TB

per drive

Software

RAID

4×PCIe3.0 ×4

direct

connection

via VPX P1,

 max 8GT/s

N/AN/AN/A

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A0116U VPX

VPX

SerDes lanes

No PCIe switch

No PCIe

8×

SATA-II

SSD

4TB (SLC)

/

8TB (MLC)

SATA-II

3Gbps,

hot-swap,

NCQ

Single disk

 ≥200MB/s

Total

≥1.5GB/s

N/AN/A

Cooling

N/A

0℃~+70℃

standard

Wide temp

Optional

EL12PRCA6A012

3U VPX

4/5HP

PEX8725

PCIe switch

(SM8724

domestic

optional)

3×

M.2 NVMe

2280

24TB /

12TB

 (domestic

SSD),

Software

RAID

PCIe3.0 ×8

via

VPX P1

2GB/s

Write

 /

5.7GB/s

Read

 (RAID0)

Windows 7/10

Linux

N/A

Conduction

 /

Air Cooling

-20~+60℃

/

-40~+70℃

EL12PRCA6A013

3U VPX

 VITA65

PEX8725

PCIe switch

Onboard FPGA

 PCIe RAID

Controller

4×

M.2 NVMe

M-Key

(2280/22110, double-sided SSD)

8TB,

HW RAID

/ JBOD,

pre-config

at factory

PCIe3.0

Gen3 ×8

via

VPX P0/P1

Total

 throughput

≥6GB/s

N/AUnloaded ≤5W; Idle ≤12W; Read ≤23W; Write ≤26W

-40℃~+85℃

 (SSD

dependent)

Cooling

N/A














VPX High-Speed Recorder | Selection Table

Part Number

Form

Factor

Core

Chip

Storage

Interface &

Disk Count

Max

Capacity

PCIe

Spec

Bandwidth

Supported

 OS

Power

Consumption

Cooling &

Operating

Temp

EL12PRCA6A0146U VPX

XC7K325T

 FPGA

4×

mSATA

(SLC /

MLC NAND)

8TB,

 FPGA-based

HW RAID0,

Detachable

storage module

design

No PCIe

P1: SRIO×4@

6.25Gbps/lane

P4: SGMII GbE

 Front: QSFP+

optical

Read

1.7GB/s

 /

Write

1.6GB/s

Windows

 64-bit

(BSP optional)

Max 2.5A@+12V (static 12W)

Air cooling

 -40℃~+85℃

EL12PRCA6A015

6U VPX

 5HP

FPGA

GTH-based,

12 backplane

GTH lanes

SSD

media

(capacity

configurable)

8TB /

 16TB /

32TB

12×GTH

(Aurora/SRIO)

P4: PCIe2.0×4

offload

4×GbE

2×10GE

Sustained

 R/W

≥5GB/s

Kylin

 Windows7/10

≤100W (32TB)

Conduction

 /

Air Cooling

-40℃~+55℃

EL12PRCA6A0166U VPX

2×XC7K325T

 FPGA

8×

mSATA

(SLC /

MLC NAND)

8TB,

 FPGA-based

HW RAID

0

PCIe

Gen2 ×8

@5Gbps/lane

P1:

4×SRIO ×4

@5Gbps/lane

Write

3.2GB/s

 /

Read

3.0GB/s

Windows

 64-bit

(BSP optional)

Max 2.5A@+12V (static 12W)

Air Cooling

 -40℃~+85℃

EL12PRCA6A0176U VPX

XCKU115

 + XC7Z100,

16GB DDR4

1~6×

M.2 NVMe

SSD

Max 24TB,

 FPGA-based

HW RAID

0/5/6/10

Backplane:

6×

4x RapidIO,

1×GbE;

No PCIe

host interface

Sustained

 R/W

>10GB/s

Windows

 (GUI + API)

N/A

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A0186U VPX

XC7VX690T

 (default) /

XC7VX485T /

XC7VX550T

+ XC7Z020

Up to 16×

mSATA

SSD

16×1TB

 mSATA

supported

FMC+ VITA57.4 HSPC, 84 high-speed differential pairs;

reserved SFP+ optical;

GbE front /

backplane

N/A

Windows

Linux

N/A

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A0196U VPX

XC7VX690T

(default) /

XC7VX485T /

XC7VX550T

+ XC7Z020

Up to 16×

mSATA

SSD

16×1TB

 mSATA

supported

FMC+ VITA57.4 HSPC,

84 high-speed differential pair

Reserved SFP+ optical;

GbE front /

backplane

N/A

Windows

 Linux

N/A

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A0206U VPX

XCKU115

 + XC7Z100

+ STM32,

16GB DDR4

1~6×

M.2 NVMe

SSD

Max 24TB,

 FPGA-based

HW RAID

0/5/6/10

Backplane:

6×4×RapidIO,

1×GbE,

LVDS,

RS485;

No PCIe

host interface

Sustained

 R/W

>10GB/s

Windows

 (control

software

+ API)

N/A

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A021

6U VPX

 5HP

FPGA,

PCIe/GTH

-based

SSD

media

(capacity-based

configuration)

4TB /

 8TB /

16TB

PCIe2.0 ×4

+ GTH ×4

(Aurora/SRIO)

P4:

PCIe2.0×4

offload

Sustained

 R/W

≥3GB/s

Kylin

 Windows7/10

≤50W (16TB configuration)

Conduction

 /

Air Cooling

-40℃~+55℃

EL12PRCA6A022

3U OpenVPX

VITA48

REDI

XC7K325T /

XC7K410T

1~2×

SATA

SSD

16TB /

 32TB

1×QSFP+

(4×10G),

configurable

SRIO×4;

20CH LVDS /

40 single-ended I/O

Single

subcard

1.6~1.9GB/s;

 dual

subcards

3.2~3.8GB/s

Windows XP/7N/A

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A023

3U VPX

 5HP

FPGA,

GTH-based

4-disk

SSD

configuration

(SSD media)

4TB /

 8TB /

16TB /

32TB

P1:16×GTH

(Aurora/SRIO);

P2: PCIe3.0×8,

 2×GbE,

1×SFP+

10GE

Sustained

 R/W

≥4.8GB/s

Kylin,

Windows7/10

CentOS7

≤80W peak

Cooling type:

N/A

-40℃~+55℃

/

0℃~+55℃

EL12PRCA6A0246U VPX

XCZU19EG

 + PEX8796

PCIe Switch

8×

M.2 SSD

(2230 /42 /80)

2MB MRAM

eMMC

BPI Flash

N/A

PCIe3.0

×16/×8,

 SRIO2.0 ×4,

Aurora ×16,

GbE

Concurrent

 write

≥8.1GB/s

/

read

≥10.2GB/s

N/A67W max

Cooling type:

N/A

0℃~+55℃

EL12PRCA6A0256U VPX

XC7VX690T /

 XCKU060

(optional)

1~4×

M.2 NVMe

SSD

(per disk

PCIe3.0 ×4)

Max 64TB,

 FPGA-based

HW RAID

0/5

7×SRIO ×4,

Aurora,

24p LVDS,

SFP+ optical,

4×PCIe ×4

Total

 ≥8GB/s

EXFAT

 file system

FTP

access

N/A

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A0266U VPX

XCKU115

+ XC7Z100

+ STM32

1~6×

M.2 NVMe

SSD

Max 24TB,

FPGA-based

 HW RAID

0/5/6/10

Backplane:

6×SRIO ×4,

GbE /

Gb optical,

LVDS,

4×RS485

Sequential

 read

/

write

>10GB/s

Windows

 (control

software

& API)

N/A

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A027

6U VPX

 VITA46

2× XC7K325T

8×

mSATA

SSD

8TB,

 FPGA-based

HW RAID

0

4×SRIO ×4

@5Gbps,

2×PCIe ×4,

64ch LVDS,

2×GbE

2GB/s

 at RAID0

/ADC12V / 5A

Air Cooling

 -40℃~+70℃

EL12PRCA6A028

6U VPX

 5HP

XCKU115

8×

M.2 NVMe

SSD

8TB /

 16TB /

32TB /

64TB

4×GTH×4

Aurora

+ PCIe3.0×4

backplane;

front + rear

10/1 GbE

Sustained

 R/W

≥10GB/s

EXFAT

 file system

FTP

service

≤100W

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A029

6U VPX

 5HP

XCKU060

4×

 M.2 NVMe

SSD

4TB /

 8TB /

16TB

2×GTH×4

Aurora

backplane;

front+ reserved

rear 10/1 GbE,

reserved LVDS

Sustained

 R/W

≥4.8GB/s

EXFAT

 file system

FTP

service

≤60W

Conduction

 /

Air Cooling

Temp:

N/A

EL12PRCA6A030

6U OpenVPX

 VITA65

Xilinx

7-Series

FPGA, ,

2GB DDR3

5/10×

mSATA

SSD

8TB

 FPGA-based

HW RAID

0/5/10/50/51

Backplane: 2×4x +1×2x RapidIO on VPX P1; Backplane P4:1×GbE; Front panel:10G SFP optical,1×GbE, UART; no PCIe host interface listed

Sustained

 >2.5GB/s,

Burst

>6GB/s

Custom

 file system /

raw sector

addressing

<60W

Conduction

 /

Air Cooling

-40℃~+80℃

EL12PRCA6A031

6U VPX

 4HP

VITA46/

VITA48/

VITA65

Xilinx

7-Series

FPGA

8×

2.5" SSD

8TB /

 16TB /

32TB

4×

QSFP+/SFP+

 (SRIO, Aurora, 10GE),

2×GbE,

RS232×3,

RS422×1,

2×SFF8644

SAS3.0, FMC

Sustained

 3.2~3.8GB/s;

with RTM

up to

7.2GB/s

N/ADC5V or DC7V~14V wide input

Conduction

 /

Air Cooling

Temp:

N/A













PN.: EL12PRCA6A001




Block Diagram





PN.: EL12PRCA6A002



Block Diagram





PN.: EL12PRCA6A003



Block Diagram





PN.: EL12PRCA6A004



Block Diagram





PN.: EL12PRCA6A005



Block Diagram





PN.: EL12PRCA6A006



Block Diagram





PN.: EL12PRCA6A007



Block Diagram





PN.: EL12PRCA6A008



Block Diagram





PN.: EL12PRCA6A009



Block Diagram





PN.: EL12PRCA6A010



Block Diagram





PN.: EL12PRCA6A011



Block Diagram





PN.:  EL12PRCA6A012



Block Diagram





PN.: EL12PRCA6A013



Block Diagram





PN.: EL12PRCA6A014



Block Diagram





PN.: EL12PRCA6A015



Block Diagram





PN.: EL12PRCA6A016



Block Diagram





PN.: EL12PRCA6A017



Block Diagram





PN.: EL12PRCA6A018



Block Diagram





PN.: EL12PRCA6A019



Block Diagram





PN.: EL12PRCA6A020



Block Diagram





PN.: EL12PRCA6A021



Block Diagram





PN.: EL12PRCA6A022

OpenVPX MOD3-PAY-2F1F2U-16.2.1-n Compliant


Block Diagram





PN.: EL12PRCA6A023



Block Diagram





PN.: EL12PRCA6A024



Block Diagram





PN.: EL12PRCA6A025



Block Diagram





PN.: EL12PRCA6A026



Block Diagram





PN.: EL12PRCA6A027



Block Diagram





PN.: EL12PRCA6A028



Block Diagram





PN.: EL12PRCA6A029



Block Diagram





PN.: EL12PRCA6A030



Block Diagram





PN.: EL12PRCA6A031



Block Diagram








INQUIRY

CATEGORIES

CONTACT US

Contact: Windy Lian

Phone: 13862120662

E-mail: sales@north-bridges.com

Whatsapp:

Add: Suzhou City, China
